Indexing in a Milling Machine

Indexing in a Milling Machine

Indexing in a milling machine involves rotating a workpiece in precise increments to achieve specific patterns or features, such as gear teeth or bolt heads.compound indexing in milling machine This is done using a variety of indexing mechanisms and plates. One method, called differential indexing, uses a gear-based differential to split each rotation into tiny increments. This allows machinists to control the workpiece in a way that opens up new accuracy and flexibility in milling applications.

Differential indexing is commonly performed on CNC mills, but it's also possible to perform it manually.compound indexing in milling machine It requires a dividing head and a special index plate with holes that can fit the divider head's center, along with an index crank. The machinist then places the part in the chuck or collet, adjusts the indexing mechanism and turns the crank handle. Each time the crank is turned, the dividing head rotates the workpiece in the specified increment.

The number of indexing movements required depends on the pattern or divisions needed and the number of spaces per hole in the index plate.compound indexing in milling machine The process involves a complicated series of calculations, and the machinist must carefully choose the appropriate index plate to avoid making mistakes. A misunderstanding of the calculation or an incorrect choice of indexing plate can lead to inaccurate results, which could be costly to a manufacturing operation.

An important tool used in indexing is the dividing head, which is attached to the worm shaft in a milling machine's headstock.compound indexing in milling machine The dividing head can be divided into several sections to accommodate various kinds of workpieces, including gears, splines, and hexagons. The dividing head can also be equipped with a chuck, a faceplate and a center rest to support long workpieces.

There are two main types of indexing in a milling machine: simple indexing and compound indexing. The former uses a plain indexing head or universal dividing head with a worm and worm wheel. The latter combines separate simple indexing movements for more complex divisions.

To perform simple indexing, a machinist must choose the proper index plate, which consists of a circle with evenly spaced holes. The machinist must then count the holes to find out how many turns the index crank needs to make for each revolution of the dividing head. For example, if the workpiece is to be milled into a six-sided hexagon, a machinist must calculate the index crank movement for each cut by counting the number of holes in a 21-hole circle.

Direct indexing is typically preferred when rapid and simple indexing is required, but for a number of divisions that cannot be achieved through simple indexing by the standard index plates frequently supplied with the dividing head, a procedure known as compound indexing is necessary. During compound indexing, the index plate is loosely held on the shaft of the dividing head with a separate index pin. The index crank is then used to index the dividing head in the same manner as it would be in a normal non-compound indexing situation.
